The double-channel T-shirt bag making machine is a cutting-edge automated equipment designed exclusively for T-shirt bag production, including shopping bags and handle bags. Its core advantage lies in dual-track synchronous operation, enabling two independent bag production lines to work simultaneously—doubling output compared to single-channel machines. With a maximum speed of 400 pcs/min and an 80% efficiency increase, this automated bag making line realizes full-process automation from film feeding to stacking, eliminating manual intervention. Its compact design saves 30% floor space, making it perfect for supermarkets, retail chains, and packaging factories seeking high-efficiency, space-saving bag manufacturing solutions.
The Double-Channel Bag Maker’s unique double-channel design integrates two parallel production tracks, operating synchronously to produce two batches of T-shirt bags at once. This innovative structure boosts output to 400 pcs/min, significantly exceeding the capacity of traditional single-channel machines. It maintains consistent quality across both channels, ensuring uniform bag size and sealing strength.
From film feeding, bottom sealing, and punching to cutting and stacking, the entire production process is fully automated. No manual operation is required, reducing labor costs and human errors. The servo motor-driven system ensures smooth coordination between each process, achieving continuous, uninterrupted production.
Equipped with high-precision photoelectric sensors, the Bag Maker automatically aligns printing patterns on the film. It detects deviations in real time and performs auto-correction, ensuring that logos, texts, or patterns on finished bags are accurately positioned—critical for branded packaging.
The machine features intelligent protection against material absence, film breakage, and mechanical jamming. Once an abnormality is detected, it immediately stops operation and triggers an alarm, preventing equipment damage and reducing waste. This feature enhances operational safety and extends the machine’s service life.
Optimized structural design reduces the machine’s footprint by 30% compared to conventional models. It can fit into limited workshop spaces without compromising production capacity, making it an ideal choice for small to medium-sized packaging facilities.
Parameter | Specification |
Machine Model | DCM-400 |
Suitable Materials | HDPE/LLDPE Thin Films (0.008-0.06mm) |
Production Capacity | Up to 400 pcs/min (Dual-Channel Synchronous) |
Maximum Bag Width | 500mm (Customizable) |
Bag Type | T-shirt Bags, Shopping Bags, Handle Bags |
Power Supply | 380V/50HZ (Depends on local voltage) |
Machine Dimension (L×W×H) | 4800×2200×3500mm |
Driving Motor Power | 7.5kw |
Sealing Method | Hot Knife Sealing |
Positioning System | Photoelectric Sensor (Pattern Alignment & Deviation Correction) |
Protection Functions | Material Absence Alarm, Film Breakage Stop, Jamming Protection |
Take-Up & Stacking | Automatic Stacking (Max Stack Height: 300mm) |
Control System | PLC Touch Screen Control |
Optional Devices | Automatic Film Unwinder, Logo Printing Module |
The high speed of 400 pcs/min meets the large demand for shopping bags in supermarkets during peak hours. The uniform sealing ensures the bags can carry heavy groceries without tearing, and the pattern alignment function supports branded packaging.
Ideal for small retail stores and convenience stores. The compact machine fits into limited backstore spaces, and the automated production reduces the need for manual labor. It can produce small-batch, customized bags to match the store’s branding.
Suitable for manufacturing promotional bags for events, exhibitions, or brand campaigns. The precise pattern positioning ensures logos and promotional messages are clearly displayed, enhancing brand visibility. The high production speed enables quick delivery for time-sensitive promotions.
Produces lightweight yet durable bags for packaging fruits, vegetables, snacks, and other daily necessities. The machine’s low material waste rate reduces production costs, making it cost-effective for mass production.
Doubled Production Capacity: Dual-track synchronous operation doubles output compared to single-channel machines, meeting high-volume production demands efficiently.
Significant Labor Savings: Full automation eliminates manual processes, reducing labor costs by up to 70% and minimizing human errors.
Space Optimization: 30% smaller footprint than traditional models, maximizing workshop space utilization for other equipment.
Precision Pattern Alignment: Photoelectric sensor technology ensures accurate pattern positioning, improving the aesthetic quality of branded bags.
Reliable Operational Safety: Triple auto-protection mechanism prevents equipment damage and waste, ensuring stable long-term operation.
It can produce up to 400 pcs/min with dual-channel synchronous operation—80% more efficient than single-channel machines.
Yes. It is equipped with photoelectric sensors that detect printing patterns and auto-correct deviations, ensuring precise alignment on every bag.
It works with HDPE and LLDPE thin films (0.008-0.06mm), the most common materials for T-shirt bag production.
Its compact design has a footprint of 4800×2200mm, saving 30% space compared to traditional bag making machines.
Routine maintenance includes cleaning the sealing knife weekly and checking the photoelectric sensor monthly. The machine’s modular design allows easy replacement of parts, ensuring minimal downtime.
